Description
Machine function:
- Adopt PLC control.
- The LED display screen shows the operation screen, and the parameter setting is convenient.
- Frequency conversion control, adjustable packing speed.
- The overlapping degree of the packaging tape can be adjusted arbitrarily according to the demand. The overlapping rate of the packaging tape is 30﹪-70﹪ to meet the customer’s requirements for the thickness of the packaging tape.
- The packaging time can be set, automatic control, one key to complete the packaging process or manual control of the start key and stop key to complete the packaging process. The operation is simple and convenient.
- The drive wheel is made of imported high-quality, high-wear, and high-temperature-resistant polyurethane, which is durable.
- The swivel can be adjusted up and down electrically to adapt to products with different outer diameters.
- The left and right guard rollers are adjustable to adapt to products of different widths.
- Manual/automatic working mode selection.
- The tightness of the packaging tape can be adjusted to better meet the needs of product packaging.
- The bottom power rollers are covered with rubber to prevent the surface of the product from being worn, and the packaging is safer. Safe, convenient, and small footprint.
Technical Parameters
Model | G200 |
Product width | 100mm |
Product OD | 500-600mm |
Product ID | 250-400mm |
Suitable for product weight | 15-500kg |
The maximum load of the machine | 500kg |
Packaging Materials | Braided belt |
Ring speed | 30-100r/min(Frequency Control) |
Roller rotation speed | 2-8m/min(Frequency Control) |
Overlapping range | 30%-70% Any overlap (adjustable) |
Swivel motor power | 1.1KW |
Panel lift motor power | 0.37KW |
Total power | About 1.5kw |
Voltage frequency | 380V/50Hz |
